ALIET/7.5.1/FT 01
COURSE PLAN (COURSE
FILES) – EACH FILE / SUBJECT / SECTION
Department: E.C.E Batch: 2017-21 Year: IV Sem: II
Name of the Faculty: Dr.K.Prasanthi Jasmine
Designation: Professor Name of the Program: B.TECH
Subject code:
RT42042
Title of the subject: EMI
No.of Students: 138
Note to faculty members on how to use this course file format
|
1. Get a new file from your office for each course and file each sheet
of these formats as and when it is complete
2. Individual Time Table and Syllabus copies provided to you shall
also be filed in it.
3. Please attach the Marks list of the students in respect of ( Continuous Assessment Exams) for this subject in your course
file
4. Photo copy of the best and the worst answer sheets for ( Continuous
Assessment Exams), be included in
the file
5. List of Assignments / Seminar Topics you have given to the students
should also include in the course file
6. Model Question Paper, which you have distributed to the students in
the beginning of the Semester for the subject should be included in the file
7. Any additional resources like OHP transparencies, handouts used
also to be filed.
|
Faculty / Date HOD/ Date
ALIET/7.5.1/FT 02
STATUS PAPER
Department: E.C.E Batch: 2017-21 Year: IV Sem: II
Name of the Faculty: Dr.K.Prasanthi Jasmine
Designation: Professor Name of the Program: B.TECH
Subject code:
RT42042
Title of the subject: EMI
No.of Students: 138
1. TARGET
a) Percentage Pass : 100%
b) Percentage I Class : 100%
2. COURSE PLAN
(Please write how you intended to cover the
contents, i.e, coverage of Units by lectures,
guest lectures Design exercise, solving numerical problems, demonstration of
models, model preparation, or by assignments, etc.,)
Lectures, Design exercise, Numerical problems, Assignments, Seminars
3. METHOD OF EVALUATION
a) Continuous Assessment Examinations ü
b) Assignments / Seminars ü
c) Mini Projects ü
d) Quiz ü
e) Term
End Examination ü
f) Others : Weekly tests in addition to
mid semester exams
4. List out any new topic(s) or any innovations you
would like to introduce in teaching the subject in this semester.
Faculty / Date HOD/
Date
ALIET/7.5.1/FT 03
GUIDELINES TO STUDY THE
SUBJECT
Department: E.C.E Batch: 2017-21 Year: IV Sem: II
Name of the Faculty: Dr.K.Prasanthi Jasmine
Designation: Professor Name of the Program: B.TECH
Subject code:
RT42042
Title of the subject: EMI
No.of Students: 138
Guidelines to
Study the subject:
Ø Refer the text books.
Ø Preparing notes with examples and numerical.
Ø Look at university question papers and cover the
topics if any were missed earlier.
Ø Searching Latest Innovations in Internet.
Ø Register for product based Company’s
University/College Program.
Faculty / Date
ALIET/7.5.1/FT 04
COURSE OBJECTIVES,
OUTCOMES
Department: E.C.E Year:
IV Sem: II
Name of the Faculty: Dr.K.Prasanthi
Jasmine
Title of the subject: EMI Subject code: R1642042
On completion of this Subject / Course the student
shall be able to:
S.No.
|
Objectives
|
Outcomes
|
1
|
Know
about the basic electronic measurements and instruments. And how to
characterize an in instrument statistically and dynamically.
|
A P
|
2
|
What are different
signal generators and internal blocks of function generators, wave analyzers.
|
B P
|
3
|
Know
about different oscilloscopes, and their internal block diagrams
|
C P
|
4
|
Learn about design
and analysis of different bridges i.e. resistive, capacitive, inductive.
|
D Q
|
5
|
Know the working of
different transducers
|
E
Q
|
6
|
Learn
about different physical parameters like force, pressure, velocity, humidity
measurement by using transducers and bridges.
|
F P
|
Note: For each of the OBJECTIVES, indicate the
appropriate OUTCOMES to be achieved.
Faculty / Date
ALIET/7.5.1/FT 05
COURSE SCHEDULE
Department: E.C.E
Name of the Faculty: Dr.K.P.JASMINE Year: IV Sem: II
Title of the subject: EMI Subject code: R1642042
The Schedule for the whole Course / Subject is :
Sl
|
Description
|
Duration (Date)
|
Total No.of Periods
|
From
|
To
|
1
|
Performance
characteristics of an instruments
|
19-11-20
|
30-11-20
|
12
|
2
|
Signal Generators
|
1-12-20
|
15-12-20
|
10
|
3
|
Oscilloscopes
|
18-12-20
|
4-1-21
|
10
|
4
|
Bridges
|
5-1-21
|
24-1-21
|
12
|
5
|
Transducers
|
4-2-21
|
18-2-21
|
10
|
6
|
Measurement of Physical
Parameters
|
19-2-21
|
2-3-21
|
10
|
Total No.of instructional periods available for the
course: 64 Hours /Periods
Faculty / Date
ALIET/7.5.1/FT 06
SCHEDULE OF INSTRUCTIONS – UNIT WISE
Department: E.C.E Unit
No: 1
Name of the Faculty: Dr.K.P.Jasmine
Year: IV Sem: II
Title of the subject: EMI Subject code: RT42042
Lecture No.
|
Date
|
Topics to be covered
|
Suggested Book
|
Page No.
|
Object No.
|
UNIT I
|
1
|
19-11-20
|
Performance Characteristics of Instruments
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[1-2]
|
1
|
2
|
20-11-20
|
Static Characteristics
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[1-2]
|
1
|
3
|
20-11-20
|
Errors in Measurement
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[2-8]
|
1
|
4
|
20-11-20
|
Dynamic Characteristics
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[9-18]
|
1
|
5
|
23-11-20
|
DC Voltmeters- Multi-range
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[74-78]
|
1
|
6
|
26-11-20
|
Range extension/Solid state Voltmeter
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[87-88]
|
1
|
7
|
27-11-20
|
Study
Hour
|
----
|
---
|
----
|
8
|
27-11-20
|
Differential Voltmeters
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[88-89]
|
1
|
9
|
28-11-20
|
AC Voltmeters- Multi range,
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[92-96]
|
1
|
10
|
28-11-20
|
AC Voltmeters- Range Extension
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[92-96]
|
1
|
11
|
30-11-20
|
AC Voltmeters-shunt
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[92-96]
|
1
|
12
|
30-11-20
|
Thermocouple type RF ammeter
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[68-70]
|
1
|
Note: Ensure that
all topics specified in the course are mentioned
Additional topics covered, if any may
also be specified
Mention the corresponding course
objective against each topic
Faculty / Date
ALIET/7.5.1/FT 06
SCHEDULE OF INSTRUCTIONS – UNIT WISE
Department: E.C.E Unit
No: 2
Name of the Faculty: Dr.K.P.Jasmine Year: IV Sem: II
Title of the subject: EMI Subjectcode: R1642042
Lecture No.
|
Date
|
Topics to be covered
|
Suggested Book
|
Page No.
|
Object No.
|
UNIT II
|
13
|
1-12-20
|
Signal Generator- fixed and variable
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[220-231]
|
2
|
14
|
3-12-20
|
AF oscillators
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[220-231]
|
2
|
15
|
5-12-20
|
Standard and AF sine and square wave signal generators
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[220-231]
|
2
|
16
|
7-12-20
|
Study
hour
|
----
|
---
|
----
|
17
|
10-12-20
|
Function Generators, Square pulse
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[220-231]
|
2
|
18
|
11-12-20
|
Random noise, sweep, Arbitrary waveform
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[220-231]
|
2
|
19
|
11-12-20
|
Wave Analyzers
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[248-258]
|
2
|
20
|
14-12-20
|
Harmonic Distortion Analyzers,
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[248-258]
|
2
|
21,22
|
15-12-20
|
Study
Hour
|
----
|
---
|
----
|
Note: Ensure that all topics specified in the course are
mentioned
Additional topics
covered, if any may also be specified
Mention the
corresponding course objective against each topic
Faculty / Date
ALIET/7.5.1/FT 06
SCHEDULE OF INSTRUCTIONS – UNIT WISE
Department: E.C.E Unit No: 3
Name of the Faculty: Dr.K.P.Jasmine Year: IV Sem: II
Title of the
subject: EMI Subject
code: R1642042
Lecture No.
|
Date
|
Topics to be covered
|
Suggested Book
|
Page No.
|
Object No.
|
UNIT III
|
23
|
18-12-20
|
Oscilloscopes CRT features
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[163-179]
|
3
|
24
|
18-12-20
|
vertical amplifiers, horizontal deflection system
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[163-179]
|
3
|
25
|
12-12-20
|
sweep, trigger pulse
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[163-179]
|
3
|
26
|
12-12-20
|
delay line, sync selector circuits
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[163-179]
|
3
|
27
|
19-12-20
|
Simple CRO, triggered sweep CRO
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[173-175],
[177-182]
|
3
|
28
|
28-12-20
|
Dual beam CRO, Dual trace oscilloscope
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[177-182]
|
3
|
29
|
29-12-20
|
Study
Hour
|
|
|
3
|
30
|
31-12-20
|
Storage Oscilloscope,
digital readout oscilloscope, digital storage oscilloscope
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[189-193]
[212-215]
|
3
|
31
|
2-1-21
|
Lissajous method of frequency measurement, standard
specifications of CRO,
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[194-196],
[203-208]
|
3
|
32
|
4-1-21
|
probes for CRO, Active & Passive, attenuator type
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[203-208]
[208-210]
|
|
Faculty / Date
ALIET/7.5.1/FT 06
SCHEDULE OF INSTRUCTIONS – UNIT WISE
Department: E.C.E Unit
No: 4
Name of the Faculty: Dr.K.P.Jasmine
Year: IV Sem: II
Title of the subject: EMI Subject
code: R1642042
Lecture No.
|
Date
|
Topics to be covered
|
Suggested Book
|
Page No.
|
Object No.
|
UNIT IV
|
33
|
5-1-21
|
AC Bridges Measurement of inductance-
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[323-324]
|
4
|
34
|
7-1-21
|
Maxwell’s bridge
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[323-324]
|
4
|
35
|
8-1-21
|
Anderson bridge
|
Electronic Measurements
& Instrumentations by K. Lal Kishore, Pearson Education – 2005.
|
[243-245]
|
4
|
36
|
8-1-21
|
Measurement of capacitance -Schearing Bridge
|
Electronic Measurements &
Instrumentations by K. Lal Kishore, Pearson Education – 2005.
|
[240-241]
|
4
|
37
|
9-1-21
|
Schearing Bridge
|
Electronic Measurements
& Instrumentations by K. Lal Kishore, Pearson Education – 2005.
|
[240-241]
|
4
|
38
|
11-1-21
|
Wheat stone bridge
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[305-312]
|
4
|
39
|
18-1-21
|
Wien Bridge
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[329-331]
|
4
|
40
41
|
19-1-21
21-1-21
|
Errors and precautions in using bridges
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[274-283]
|
4
|
42
43
|
22-1-21
23-1-21
|
Q-meter.
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[274-283]
|
4
|
44
|
24-1-21
|
Q-meter.
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[274-283]
|
4
|
Note: Ensure that all topics specified in the course are
mentioned
Additional topics
covered, if any may also be specified
Mention the
corresponding course objective against each topic
Faculty / Date
ALIET/7.5.1/FT 06
SCHEDULE OF INSTRUCTIONS – UNIT WISE
Department: E.C.E Unit
No: 5
Name of the Faculty: Dr.K.P.Jasmine Year: IV Sem: II
Title of the subject: EMI Subject code: R1642042
Lecture No.
|
Date
|
Topics to be covered
|
Suggested Book
|
Page No.
|
Object No.
|
UNIT V
|
45
|
4-2-21
|
Active & Passive Transducers
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[375-378]
|
5
|
46
|
5-2-21
|
Resistance Based Transducer
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[378-381]
|
5
|
47
|
5-2-21
|
Capacitance Based Transducer.
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[415-417]
|
5
|
48
|
6-2-21
|
Inductance Based Transducer, Strain gauges
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[398-402]
|
5
|
49
|
8-2-21
|
Strain
Gauge- wire type, foil type
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[383-393]
|
5
|
50
|
11-2-21
|
Strain
Gauge- semiconductor type
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[383-393]
|
5
|
51
|
12-2-21
|
LVDT, Sensistors
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[404-408]
|
5
|
52
|
13-2-21
|
Piezo Electric transducers
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[418-419]
|
5
|
53
|
15-2-21
|
Resistance Thermometers
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[393-396]
|
5
|
54
|
16-2-21
|
Thermocouples, Thermistors
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[68-73]
|
5
|
Note: Ensure that all topics specified in the course are
mentioned
Additional topics
covered, if any may also be specified
Mention the
corresponding course objective against each topic
Faculty / Date
ALIET/7.5.1/FT 06
SCHEDULE OF INSTRUCTIONS – UNIT WISE
Department: E.C.E Unit
No: 6
Name of the Faculty: Dr.K.P.Jasmine Year:
IV Sem: II
Title of the subject: EMI Subject
code: R1642042
Lecture No.
|
Date
|
Topics to be covered
|
Suggested Book
|
Page No.
|
Object No.
|
UNIT VI
|
55
|
19-2-21
|
Measurement of physical parameters
|
Electronic Measurement & Instrumentation by U. A. Bakshi, A
V Bakshi, K A Bakshi, Technical Publication-2012.
|
[8.79- 8.81]
|
6
|
56
|
20-2-21
|
Force
Measurement
|
R4. Electronic Measurement & Instrumentation by U. A. Bakshi, A
V Bakshi, K A Bakshi, Technical Publication-2012.
|
[8.79- 8.81]
|
6
|
57
|
22-2-21
|
Pressure
|
R4. Electronic Measurement & Instrumentation by U. A. Bakshi, A
V Bakshi, K A Bakshi, Technical Publication-2012.
|
[8.84]
|
6
|
58
|
23-2-21
|
Velocity
|
R4. Electronic Measurement & Instrumentation by U. A. Bakshi, A
V Bakshi, K A Bakshi, Technical Publication-2012.
|
[8.66-8.67]
|
6
|
59
|
25-2-21
|
Humidity
|
R4. Electronic Measurement & Instrumentation by U. A. Bakshi, A
V Bakshi, K A Bakshi, Technical Publication-2012.
|
[8.62- 8.66]
|
6
|
60
|
26-2-21
|
Moisture
|
R4. Electronic Measurement & Instrumentation by U. A. Bakshi, A
V Bakshi, K A Bakshi, Technical Publication-2012.
|
[8.60- 8.62]
|
6
|
61
|
26-2-21
|
Speed&
Velocity
|
R4. Electronic Measurement & Instrumentation by U. A. Bakshi, A
V Bakshi, K A Bakshi, Technical Publication-2012.
|
[8.66- 8.67]
|
6
|
62
|
27-2-21
|
Study
Hour
|
----
|
---
|
----
|
63
|
1-3-21
|
Displacement
, Proximity
|
R4. Electronic Measurement & Instrumentation by U. A. Bakshi, A
V Bakshi, K A Bakshi, Technical Publication-2012.
|
[8.41- 8.42]
|
6
|
64
|
2-3-21
|
Data Acquisition Systems(DAS)
|
Electronic instrumentation, second edition - H.S.Kalsi, 2004.
|
[600 - 605]
|
6
|
Note: Ensure that all topics specified in the course are
mentioned
Additional topics
covered, if any may also be specified
Mention the corresponding
course objective against each topic
Faculty / Date
ALIET/7.5.1/FT 07
COURSE COMPLETION STATUS
Department: E.C.E
Name of the Faculty: Dr.K.P.Jasmine Year: IV Sem: II
Title of the subject: EMI Subject code: R1642042
Actual date of completion and remarks if any :
Unit
|
Remarks
|
No of
Objectives achieved
|
1
|
Nil, Completed
|
1
|
2
|
Nil, Completed
|
2
|
3
|
Nil, Completed
|
3
|
4
|
Nil, Completed
|
4
|
5
|
Nil, Completed
|
5
|
6
|
Nil, Completed
|
6
|
Note: After completion of each unit, mention the no of
objectives achieved.
Faculty / Date
ALIET/7.5.1/FT 08
RECORD OF TUTORIAL CLASS
CONDUCTED
Department: E.C.E
Name of the Faculty: Dr.K.P.Jasmine Year: IV Sem: II
Title of the subject: EMI Subject
code: R1642042
This tutorial correspondents
to Unit No’s 1, 2,3,4,5,6:
1.
Define the sensitivity of a
multimeter. Draw the block diagram of a simple multimeter and explain its
operation?
2.
A shunt type ohmmeter uses a
basic meter with a full scale current of 2ma and an internal resistance of 25Ω.
The battery has an emf of 1.5v. Find (i)The value of resistance R1, (ii) At
what point will 100Ω be marked on the scale?
3.
Draw the block diagram of a function
generator and explain the method of producing sine wave?
4.
Draw the neat diagrams of
horizontal deflection systems and explain briefly about their working?
5.
a) Draw and explain the
principle and working of a Dual Trace Oscilloscope?
b) Explain the operation of 10 : 1 probe
in detail?
6. Explain
the concept of strain gauges and thermocouples in detail?
7. How are Transducers classified? Give
examples and briefly explain about the Principle of operation of each of them.
8.
Explain the working of the following piezoelectric transducers:
(a)Force (b)Strain ( c ) Torque ( d )
Pressure
-----------------------------------------------------------------------------------------------
Note: Please write the Questions / Problems/Exercises which you would like
to give to the students and also mention the objectives to which these
questions /problems are related.
-----------------------------------------------------------------------------------------------
Faculty / Date
ALIET/7.5.1/FT
09
LESSON PLAN
Date:
Department: ECE Title of subject: EMI
Subject code: R1642042 Lesson Number:1-6
INSTURCTIONAL
OBJECTIVES:
On completion of this lesson the student should be
able to
Unit 1: Know about the basic
electronic measurements and instruments. And how to characterize an in
instrument statistically and dynamically.
|
Unit 2: What are different signal generators
and internal blocks of function generators, wave analyzers.
|
Unit 3: Know
about different oscilloscopes, and their internal block diagrams
|
Unit 4: Learn about design and analysis of
different bridges i.e. resistive, capacitive, inductive.
|
Unit 5: Know the working of different
transducers
|
Unit 6:
Learn about different physical parameters like force, pressure, velocity,
humidity measurement by using transducers and bridges.
|
|
|
TEACHING AIDS: Chalk and board.
TEACHING POINTS:
Faculty/Date
ALIET/7.5.1/FT
10
LESSON
NOTES
Department : …….ECE……… Name of the faculty : Dr.K.P.Jasmine
Subject:
Electronic Measurement and Instrumentation
Date:
Sl
|
Unit
/ Topic Name
|
Book
Title Name
|
Author
|
Books referred
|
Teaching Methodology / Module
|
1.
|
Performance
characteristics of an instruments
|
Electronic instrumentation,
|
H.S.Kalsi
|
R4. Electronic Measurement &
Instrumentation by U. A. Bakshi, A V Bakshi, K A Bakshi, Technical
Publication-2012.
|
Chalk
and black board
|
2.
|
Signal
Generators
|
Electronic instrumentation,
|
H.S.Kalsi
|
R4. Electronic Measurement &
Instrumentation by U. A. Bakshi, A V Bakshi, K A Bakshi, Technical
Publication-2012.
|
Chalk
and black board
|
3.
|
Oscilloscopes
|
Electronic instrumentation,
|
H.S.Kalsi
|
R4. Electronic Measurement &
Instrumentation by U. A. Bakshi, A V Bakshi, K A Bakshi, Technical
Publication-2012.
|
Chalk
and black board
|
4.
|
Bridges
|
Electronic instrumentation,
|
H.S.Kalsi
|
R4. Electronic Measurement &
Instrumentation by U. A. Bakshi, A V Bakshi, K A Bakshi, Technical
Publication-2012.
|
Chalk
and black board
|
5.
|
Transducers
|
Electronic instrumentation,
|
H.S.Kalsi
|
R4. Electronic Measurement &
Instrumentation by U. A. Bakshi, A V Bakshi, K A Bakshi, Technical
Publication-2012.
|
Chalk
and black board
|
6.
|
Measurement of Physical
Parameters
|
Electronic instrumentation,
|
H.S.Kalsi
|
R4. Electronic Measurement &
Instrumentation by U. A. Bakshi, A V Bakshi, K A Bakshi, Technical
Publication-2012.
|
Chalk
and black board
|
Prepared:
Verified:
Faculty:
HOD :
ALIET/7.5.1/FT
12
Department: E.C.E Date: 27-11-17
Academic year: 2018-19
Class/Semester: II FACULTY
NAME: Dr.K.PRASANTHI JASMINE LOAD=15
Faculty/
Date
Time Table In-charge/Date HOD/Date
